Take Control of Your Pneumatic Systems with the Reliable RM Series 3/2 Way Solenoid Valve
The 3/2 Way Single Solenoid Valve is used to control the flow of compressed air. It comes in a variety of models, sizes, and technical specifications. The valve has a variety of coil voltages, pressures, and temperatures. It is also rated for continuous duty and has an IP 65 protection rating.
For applications requiring a specific valve design, our poppet type 3/2 way single solenoid valve provides a unique solution with distinct benefits. For budget-friendly options without compromising on performance, our affordable 3/2 way single solenoid valve offers a cost-effective solution for various applications.
| Technical Specifications |
| Product Name |
3/2 Way Single Solenoid Valve |
| Model |
2ARMSS – 302 |
2ARMSS – 304 |
| Size |
1/4″ |
1/2″ |
| Orifice |
6.5 |
12.5 |
| Design |
Spool type, Internal Pilot Operated ( External Pilot On Request) |
| Pressure |
2.5 to 10 Kg/cm² |
| Temperature |
80 °C |
| Leakage |
Bubble Tight |
| Duty Cycle |
Continuous Rated |
| Protection |
IP 65 [Flameproof / Explosion Proof As Per IS / IEC 60079 – 1 Standard
Approved by Central Institute of Mining and Fuel Research (CIMFR)] |
| Connector |
DIN 43650 A |
| Response Time |
15 msec ON / 25 msec OFF |
| Coil Voltage |
12V, 24V, 48V, 110V, 230V, (AC / DC) 50 / 60 Hz
( Non Std. Voltage Available On Request ) |
| Media |
Compressed Air ( Filtered & Lubricated ) |
Flow (NLPM)
at 5 BAR |
1100 |
3000 |
| Weight (Kg) |
0.66 |
1.19 |
